EinScan Rigil is the world’s first Tri-Mode 3D scanner with built-in computing, wireless solution and hybrid light technology. EinScan Rigil offers a fully integrated 3D scanning wireless workflow with triple work modes that effectively eliminates the traditional compromise between computing power and flexibility.
It provides high quality models with 0.04 + 0.06 mm/m volumetric accuracy and high geometric resolution up to 0.05 mm. Its hybrid types of light sources — 19+19 crossed laser lines, 7 parallel blue laser lines, and infrared VCSEL — which paired with two separate groups of tailored cameras to ensure versatile performance and peak efficiency for objects of wide-range of sizes and surface types.
IR RapidVCSEL Infrared-powered scanning solution for high efficiency and wide coverage of medium to large objects, with eye safe portrait scanning.
2 Groups of Cameras and Projectors
EinScan Rigil’s 2 separate groups of cameras are specifically designed to capture different light sources, enables best adaptability to laser and IR light source respectively; to achieve better data recognition under strong environmental light, to ensure precise data captured even in complex lighting environments.
Unlock MAX Performance And Flexibility
The EinScan Rigil offers three operating modes:
No PC connection required, all scanning and processing tasks are completed directly on the hardware, delivering exceptional portability and ease of use.
Leveraging built-in Wi-Fi 6, this mode enables seamless wireless scanning and allows connection to a powerful computer, optimizing performance for complex tasks.
Maintaining availability and maximum scanning speed and data volume in complex network environments, optimizing performance for complex tasks.
EinScan Rigil features a special tracking algorithm, which provides marker-free blue laser scanning through a Laser + IR hybrid scan mode currently available in EXScan Rigil PC software. This enables better efficiency than traditional marker-based laser scanning and better data quality than marker-free IR scanning.
Both Blue Laser and Infrared VCSEL projectors have strong environment light adaptability, which ensure smooth scanning experience under strong sunlight.
EinScan Rigil is equipped with a 5MP high-definition camera that can restore high-quality texture details, allowing designers, engineers and artists to maintain high-fidelity modeling and rendering during the digitization process, providing more precise information for subsequent analysis and creation.
EinScan Rigil is designed to comprehensively address the 3D modeling needs of consumers in the automotive aftermarket industry.
It significantly enhances efficiency in generating high-quality 3D models, combining fast scanning capabilities, streamlined professional workflows, lightweight computing solutions, and rich data editing functions.
EXScan Rigil is a dedicated PC software designed specifically for the EinScan Rigil scanner, covering the full spectrum of advanced professional scanning workflows, scanning, data modification, closed surface generation, model editing, to export and sharing.
When paired with the EinScan Rigil scanner, it delivers a seamless, flexible, and portable scanning experience that combines stability and high-quality results
| Device | EinScan Rigil | |||
|---|---|---|---|---|
| Work Mode | Wireless Standalone For extra computing resource: PC- Wireless / PC-Wired | |||
| Scan Mode | Laser HD | IR Rapid | ||
| Light Source | 19+19 crossed laser lines | 7 blue laser parallel lines | IR VCSEL | |
| Resolution | 0.05 ~ 10 mm | 0.2 ~ 10 mm | ||
| Scanning Speed | 4,400,000 points/s | 940,000 points/s | 1,600,000 points/s | |
| Working Distance | 170 ~ 550 mm | 160 ~ 1500 mm | ||
| Alignment Mode | Global Markers / Markers / Features / Hybrid | Global Markers / Markers / Features / Texture / Hybrid | ||
| Volumetric Accuracy | Up to 0.04 + 0.06 mm/ m | Up to 0.1 + 0.4 mm/m | ||
| Camera Resolution | 3D: 2.3MP*2 1.3MP*2; Texture: 5MP | |||
| Output Formats | STL, OBJ, PLY, 3MF, ASC | |||
| Laser Class | Class II | / | ||
| Hardware | CPU: 8 core, 2.4GHz; Hard Drive: 1T SSD ROM; 32GB DDR5 RAM; 6.4”2K AMOLED Touch Screen | |||
| Operation Conditions | Temperature -10℃ ~ 40℃ | |||
| Certifications | CE, FCC, ROHS, WEEE, FDA, SRRC, IP50 | |||
| Recommended Configurations for PC | Win11, Professional 22H2 (64-bit);Graphics card: NVIDIA GeForce RTX 3060 Laptop GPU or above; VRAM: 8 GB or above;RAM: 64 GB or above, DDR5 dual-channel; Interface: USB 3.0;Processor: 13th Gen Intel® Core™ i7-13700H or above; | |||
| Interface & Power Source | USB Type-C Battery: 6000mAh*2; Support 60W-PD3.0 Charger | |||
| Dimension | (H*D*W) 233 × 180 × 72.8 mm | |||
| Net Weight | 870 g (batteries included) | |||
